HYTE PCI-E 4.0 x16 RISER WHITE
Product Code : ACC-HYTE-PCIE40-W
2,490 ฿
Tech Specs
PCI Express Generation: 4.0 and older
PCI Express Lanes: 16
Length: 200mm
Color(s): Black, White, Red
WIRE SPECS
Conductor: 30 AWG silver plated copper
Insulation: FEP
Ground Wire: 32 AWG tinned copper
Pair Shield: Bottom, Side, Top
Pair Cover: Aluminum foil mylar tape
Outer Jacket: PET
Rated Voltage: PVC
Working Voltage and Current: 30V 12V / 5A
Warranty : 3 Years
Contact usPCIE40 4.0 Luxury Riser Cable
A Luxury Aesthetic, High Performance Riser Cable
Why We Made This
- Vertical graphics card
- EMI shielded, rigorously tested and built with high quality copper wires for ultimate PCIE 4.0 x16 bandwidth performance.
- Half-height bracket, full-height bracket? Both options are included to allow for more case compatibility.
- Only aesthetic luxury PCIE 4.0 riser cable on the market that considers your new vertical GPU set up–now in all three canopy colors–just like the Y60!
What’s in the box
- HYTE PCIE40 4.0 Riser Cable
- Full-height Bracket
- Half-height Bracket
- 6-32*6 Flat Head Screws x2
- M3*6 Self-tapping Screws x5
- Quick Start Guide
Product Features
Design
PCIE40 4.0 riser cable features a cover canopy available in 3 colors to add a premium look to vertical graphics compatible systems
Performance
Rigorously tested to comply with the PCI Express 4.0 standard, enjoy industry leading performance with full x16 bandwidth.
Stability
EMI shielded high quality copper wires guard against outside interference and crosstalk for a rock solid gaming experience.
Durability
Highly flexible ribbons are protected from damage by a plastic coating and solder points are guarded by covers at both ends to avoid damage during installation.
Compatibility
With a total of 200mm of cable length and included full and half height pcie brackets, the PCIE40 is a breeze to install and compatible with a wide range of cases on the market.
Tech Specs
PCI Express Generation: 4.0 and older
PCI Express Lanes: 16
Length: 200mm
Color(s): Black, White, Red
Warranty: 3 Years
WIRE SPECS
Conductor: 30 AWG silver plated copper
Insulation: FEP
Ground Wire: 32 AWG tinned copper
Pair Shield: Bottom, Side, Top
Pair Cover: Aluminum foil mylar tape
Outer Jacket: PET
Rated Voltage: PVC
Working Voltage and Current: 30V 12V / 5A
